High Speed Boom Barrier Gate for Highway Toll Station BLS-P09H

Brand:

BOLAN，Neutral, OEM & ODM Acceptable

Model:

BLS-P09H

MOQ:

1PC

Payment:

T/T before shipping

Delivery time:

One week(Depends on Quantity)

Start Port:

Shenzhen

Certification:

CE, ISO9001

Technology

Ultra-Fast Lifting & Lowering Response

Achieve full-cycle operation (lift/lower) within 0.3-0.6 seconds (adjustable based on model), significantly reducing vehicle queuing time at high-traffic checkpoints.

High-Precision Servo Motor Drive System

Adopt brushless servo motor or variable-frequency motor to ensure stable, low-noise operation and precise control of barrier arm movement, with strong resistance to voltage fluctuations.

Multi-Layer Safety Protection Mechanisms

Equipped with anti-crushing radar, ground induction coils, and obstacle-rebound sensors; automatically stop or reverse the barrier arm upon detecting obstacles to avoid vehicle/pedestrian damage.

Intelligent System Integration Compatibility

Seamlessly connect with license plate recognition (LPR), ETC systems, and IoT platforms; support remote control, automatic access authorization, and real-time operation status monitoring.

Rugged & Weather-Resistant Structural Design

Barrier arm is made of aluminum alloy or carbon fiber composite material, lightweight yet impact-resistant; the main chassis adopts anti-corrosion galvanized steel, suitable for outdoor all-weather operation (-40℃ to +70℃).

Adaptive Traffic Flow Regulation

Support dynamic speed adjustment function; automatically optimize barrier arm operation speed according to real-time vehicle flow density to balance throughput efficiency and operational safety.

Low-Power & Energy-Saving Operation

Adopt standby power-saving mode with ultra-low power consumption (<5W in idle state); compatible with solar power supply systems for energy-efficient and environmentally friendly operation.

Easy Maintenance & Fault Self-Diagnosis

Built-in fault self-detection module; automatically identify and report common faults (e.g., motor overload, sensor failure) to reduce maintenance time and costs.

Features

● High-Efficiency Traffic Throughput Management

Realize ultra-fast arm lifting/lowering (0.3–0.6 seconds per full cycle) to minimize vehicle queuing, especially suitable for high-traffic scenarios like toll plazas and transportation hubs.

● Authorized Vehicle Access Validation

Verify vehicle eligibility via integrated systems (LPR, ETC, or RFID) and grant quick passage only to pre-authorized vehicles, blocking unauthorized entry effectively.

● Multi-Layered Anti-Collision & Anti-Crushing Protection

Detect obstacles in real time through radar, ground loops, and infrared sensors; automatically reverse or stop the barrier arm to prevent damage to vehicles and injury to pedestrians.

● Dynamic Traffic Flow Adaptation

Adjust arm operation speed intelligently according to real-time traffic density, balancing passage efficiency during peak hours and operational safety in low-traffic periods.

● Remote Monitoring & Automated Control

Support remote operation, real-time status tracking, and IoT-based automation; enable centralized management of multiple barrier gates across different locations.

● Seamless Fee Settlement System Integration

Link with automatic toll collection or parking payment systems; trigger barrier arm lifting immediately after successful payment to streamline the settlement process.

● Emergency Passage Guarantee

Equip with backup power supply and emergency release mechanism; automatically lift the barrier arm in case of power outage or emergency to ensure unimpeded evacuation.

● Zoned Access Right Differentiation

Collaborate with access control platforms to implement differentiated passage permissions for different vehicle types (e.g., emergency vehicles, staff cars) in designated areas.

Technical Specifications

Parameter Name	Specification & Key Information
Body size	338313945mm Carbon steel with yellow, black, golden optional
Boom Length	3000mm (customizable for lane width)
Boom Material	Carbon fiber (round , different colors optional)
Opening Speed	0.3-0.6s(savor motor high speed boom barrier, for highway and high traffic flow)
Closing Speed	0.3 - 0.8 s (adjustable to avoid collision)
Driving Mode	Planetary servo motor ; with manual override for emergency
Rated Voltage	AC 110V-240V ± 10% / DC 12V/24V (for small-sized models)
Rated Power	400W - 500W (varies with boom length and model, DC motor: 80W-120W, AC motor 100W-180W, Savor motor 400-500W)
Max Load Capacity	≤ 50kg (boom load; suitable for light-duty vehicle control)
Control System	PLC / Single-chip microcomputer; supports remote control, card swiping & access control, LPR systems etc linkage
IP Rating	IP54 - IP65 (suitable for outdoor use, dust & rain resistant)
Operating Temperature	-20°C to +60°C (adaptable to common outdoor environments)
Safety Device	Infrared photoelectric sensor, ground loop detectors, traffic light optional; auto-reverse when obstacle detected

Structure and Dimensions

The core structure of BOLAN boom barrier consists of four main parts

High Speed Boom Barrier Gate for Highway Toll Station BLS-P09H 20

Drive Unit

Core power component, planetary servo motor, ensuring high speed, stable and efficient boom rotation.

High Speed Boom Barrier Gate for Highway Toll Station BLS-P09H 21

Boom Assembly

The horizontal blocking part, made of lightweight high-rigidity carbon fiber, with customizable length (3m typical)

High Speed Boom Barrier Gate for Highway Toll Station BLS-P09H 22

Control

Integrates PLC or single-chip microcomputer control module, power supply unit and wiring terminals, supporting linkage with most of access control systems on the market.

High Speed Boom Barrier Gate for Highway Toll Station BLS-P09H 23

Base & Frame

Heavy-duty steel coating colors structure fixed to the ground, providing stable support for the entire device and ensuring installation firmness.

Customization & Accessories

Integrate Solutions

★ License Plate Recognition (LPR) system
★ Ground Loop Detector/Infrared Sensor/ Radar
★ Traffic Light
★ Access Control Management System (ACMS)
★ Video Surveillance System
★ Parking lot management system
★ Toll station payment system
★ Remote Control System (via WiFi/Bluetooth)
★ Exit button

Optional Accessories

★ RFID card reader/ long range bluetooth reader
★ LPR camera
★ QR code scanner
★ Card insert, coin collector, token collector
★Traffic light
★ Inner or outer counter and screen
★ RF remote control, exit button
★ Sound Alarm
★ Any other accessories you need, please feel free to contact us for confirmation

Warranty

★ 1 year for electric parts, 2 years for other parts after delivery. More details please feel free to confirm with us.

Operating & Control

Operating ways

• One way for entry, one way for exit
• Bi-direction single passage (entry and exit by one way)
• Multi way for entry, multi way for exit

Control ways

• Access control and time attendance system: RFID card/wristband, biometric/face recognition, computer with management software can also control directly
• ESD system: ESD tester+RFID card or face recognition or not
• Ticket system: QR code wristband/ticket
• coin/token collector or RFID card insert
• Exit button
• Wireless remote control

Application Scenes

BOLAN parking barriers suit all scenarios requiring vehicle access control and management, enabling authorized entry, traffic streamlining, anti-illegal parking, and improved site security and operational efficiency.

Residential Communities

Manage resident and visitor vehicles, stop unauthorized parking, and safeguard private parking space entitlements.

Commercial Complexes & Office Towers

Streamline vehicle flow, integrate with payment systems, and boost parking resource utilization for shoppers and employees.

Municipal/Roadside Public Parking Lots

Standardize entry-exit procedures, simplify centralized fee collection, and uphold orderly public parking operations.

Industrial Parks & Manufacturing Sites

Separate production zones from external traffic, control freight and private car access, and strengthen on-site safety.

Campuses (Schools & Universities)

Regulate pick-up/drop-off traffic, restrict non-campus vehicles, and ensure campus traffic safety.

Hospitals & Medical Facilities

Prioritize emergency vehicle passage, ease congestion, and manage parking for patients, visitors and medical staff.

Government & Institutional Premises

Tighten security by permitting only authorized official vehicles and authorized visitors.

Transportation Hubs (Airports, Railway Stations)

Guide high-volume passenger vehicles, enable fast entry-exit, and increase parking facility throughput.

Hotels & Resorts

Offer exclusive guest parking management, prevent external vehicle occupation, and upgrade guest experience.

Logistics & Warehousing Centers

Coordinate freight truck access, link with cargo scheduling systems, and ensure smooth logistics workflows.
