Sliding Gate Full Height Turnstile Pedestrian Entrance Access Security BLS-SG81
●Brushless motor drive and transmission
Delivers powerful, stable power with low noise during operation.
●Smart PLC Controller
Enables linkage with external authentication devices and supports customized access logic programming.
●Anti-collision buffers
Integrated detectors and anti-collision buffers, ensures safe, quiet, smooth operation and a long service life.
●Infrared Sensors
Multi-point infrared sensors; anti-clamp/tailgate/reverse/passback & passage confirmation;
●Auto-lock function
Automatically locks 30 seconds after activation if no passage is detected, with adjustable timing.
●Startup Self-Inspecition
Power-on key component check; fault code display; passage blocked on critical faults.
●Audio-Visual Alert & indicators
Buzzer +Multi-language voice + LED indicators
Features
● Operates quietly with stable, low-friction opening and closing.
● Quick response and high throughput for busy pedestrian flow.
● Built-in sensor to stop automatically when obstacles are detected.
● Effectively prevents unauthorized following and illegal entry.
● Supports access control systems: RFID, QR code, fingerprint, face recognition.
● Made of sturdy materials for long-term heavy-duty use.
● Energy-saving design with low running cost and long service life.
● Simple mounting process and low maintenance requirements, reducing labor costs.
● Mute design (≤45dB), quiet and smooth operation.
Technical Specifications
| Parameters | Specification |
| Material | Frame: 304/316 stainless steel, carbon steel powdered coating colors |
| Swing barriers: Tempered glass Acrylic/PC | |
| Dimensions | 1400(L) × 330mm (W) × 1020mm (H) (standard), some special models have different dimensions, also can be customized |
| Passage Width | Standard: 600mm is standard, 900mm is optional, the cabinet also need to be widen |
| Speed Performance | 0.5-0.8 seconds per person, generally 30-40persons/ min |
| Power Supply | AC 100-240V (universal voltage); |
| Control voltage: DC 24V | |
| Motor Parameters | Brushless DC motor; Power: 40-60W; Rotational speed: 3000rpm (stable and low-noise operation) |
| ≥5 million cycles; High-end models: ≥7~8 million cycles | |
| Interface | Input：relay signal; output: dry contact RS232, RS485 |
| Environmental Resistance | Indoor or semi-outdoor |
| Operating temp: -25℃ to 65℃; |
Structure and Dimensions
Bolan sliding barrier gate comprises a stainless steel or carbon steel coating main frame, paired horizontal sliding barrier (tempered glass or acrylic)panels (guided by rails for single-person access/anti-tailgating), an internal brushless motor-transmission & control unit(PLC controller main board, power supply) (connectable to external authentication devices), and embedded infrared sensors for safety.
Customization & Accessories
★ Custom Dimensions & Site Layout Design: Adapted to match your on-site layout and project-specific requirements.
★ Wide Selection of Materials & Surfaces: Available in 304/316 stainless steel or powder-coated carbon steel with custom colors; finishes include brushed, snowflake, mirror, and matte textures.
★ Customizable Internal Structure & Drive Systems: Modified to meet unique project demands and special functional requirements.
★ Expanded Interface Compatibility: Supports extended communication ports for integration with interlock systems such as AI cameras and other devices.
★ Branding & Logo Customization: Logos can be engraved or silk-screen printed on the main housing and sliding doors as requested.
★ Adjustable LED Lighting: Choose between static red cross/green arrow indicators or dynamic flowing light effects.
★ Reader Panel Customization: Customizable size, shape, logo, and text to ensure a cohesive and integrated appearance.
★ Personalized Sliding Doors: Made of tempered glass or acrylic; available in 250mm or 450mm widths with height adjustable from 1200mm to 1800mm; optional logo or slogan engraving.
★ Optional Add-On Features: Customizable audio alarms and ambient LED lighting in various colors.
★ Portable Design Option: Features a powder-coated carbon steel base for convenient movement and repositioning.
★ Dedicated Custom Support: For further inquiries or special customization needs, please visit our Custom Services page or get in touch with our team directly.
★ Fingerprint reader, face recognition
★ QR code scanner
★ Card insert, coin collector, token collector, wristband collector
★ RF remote control, exit button
★ Sound Alarm
★ Any other accessories you need, please feel free to contact us
Operating & Control
· Single-direction authorized: Access in one direction requires authorization, while the reverse direction remains locked.
· Two-way verified: Both entry and exit directions need identity verification to control pedestrian flow.
· Single-direction free: Unrestricted passage is allowed in one direction, with the opposite direction kept locked.
· Full-access / full-lock mode: Switch freely between bidirectional open passage and complete channel lockdown.
• Access control and time attendance system: RFID card/wristband, biometric/face recognition, computer with management software can also control directly
• Ticket system: QR code wristband/ticket, E-QR code
• coin/token collector or RFID card insert, wristband collector
• Exit button(optional)
• Wireless remote control(optional)
• Manual override keys(optional)
• Infrared sensor detect(factory setting optional)
•Any other control system or solutions please confirm with us
Application Scenes
