Security Entrance Sliding Gate Turnstile with Smart Access Control Solutions BLS-SG51
●DC Brushless Motor
Ultra heavy-duty high-speed drive paired with a gearbox, delivering stable, low-noise and smooth operation
●Smart PLC Controller
Built-in intelligent PLC controller, supporting linkage with external access control systems and customized access logic.
●Anti-collision buffers
Integrated detectors and anti-collision buffers, ensure safe of passengers
●Infrared Sensors
Multi-point array; anti-climb/clamp/tailgate/reverse/passback functions
●Auto-Lock Reset
Automatically lock after 30 seconds(adjustable) after receiving opening signal if nobody pass
●Power on self-inspection
Power-on self inspection all parts, fault code display; passage blocked on critical faults.
●Audio-Visual Alarm
Multi-language voice + clear LED indicators
Features
● ≥7 million cycle movement life, high-end servo motor for high-frequency use
● PLC control system for stable and accurate operation
● Fast mode up to 40 persons/min for peak flow dispersion
● Audible and visual alarm for abnormal situations (tailgating, fault)
● Standby current ≤0.5A, energy-saving and eco-friendly
● Simple installation with detailed guidelines because of modular design
● Seamless connection with existing access control management systems
● Optional emergency stop button for sudden safety incidents
● Mute design (≤45dB), suitable for quiet environments
Technical Specifications
| Parameters | Specification |
| Material | Frame: 304/316 stainless steel, carbon steel powdered coating colors |
| Swing barriers: Tempered glass Acrylic/PC/ABS | |
| Dimensions | 1400(L) × 350mm (W) × 1100mm (H) (standard), some special models have different dimensions, also can be customized |
| Passage Width | Standard: 600mm is standard, 900mm is widen wings, the cabinet also need to be widened |
| Speed Performance | 0.5-0.8 seconds per person, generally 30-40persons/ min |
| Power Supply | AC 100-240V (universal voltage); |
| Control voltage: DC 24V | |
| Motor Parameters | Brushless DC motor; Power: 40-60W; Rotational speed: 3000rpm (stable and low-noise operation) |
| ≥5 million cycles; High-end models: ≥7~8 million cycles | |
| Interface | Input：relay signal; output: dry contact RS232, RS485 |
| Environmental Resistance | Indoor or outdoor |
| Operating temp: -25℃ to 65℃; |
Structure and Dimensions
BOLAN sliding barrier gate comprises a stainless steel or carbon steel coating main frame, paired horizontal sliding barrier (tempered glass, PC or acrylic)panels (guided by rails for single-person access/anti-tailgating), an internal brushless motor-transmission & control unit(PLC controller main board, power supply) (connectable to external authentication devices), and embedded infrared sensors for safety.
Customization & Accessories
★ Fingerprint reader, face recognition
★ QR code scanner
★ Card insert, coin collector, token collector, wristband collector
★ RF remote control, exit button
★ Sound Alarm
★ Any other accessories you need, please feel free to contact us
Operating & Control
· Single-direction authorized: Permission required for one direction; the other remains locked.
· Two-way verified: Access validation needed for both entry and exit to regulate flow.
· Single-direction free: Unrestricted passage in one direction; opposite way stays locked.
· Full-access/full-lock: Toggle between two-way free flow and total channel lockdown.
• Access control and time attendance system: RFID card/wristband, biometric/face recognition, computer with management software can also control directly
• Ticket system: QR code wristband/ticket, E-QR code
• coin/token collector or RFID card insert, wristband collector
• Exit button(optional) ,Wireless remote control(optional)
• AI camera, CCTV system
• Manual override keys(optional)
• Infrared sensor detect(factory setting optional)
•Any other control system or solutions please confirm with us
